METERING SYSTEMS AND TRUCK LOADING SYSTEM

For liquid and gas applications Liquid & Gas, Upstream & Downstream

EPC DIVISION VISION

The best response customer need and leadership turnkey EPC contractor in metering skid and truck loading in oil & gas and energy Industry by one stop service

E-Engineering Design & Calculation Metering skid and Truck Loading

1. Get requirement from cutomer need
2. Basis design suitable before start up engineering design
3. Design base on international standard (API, AGA, ANSI, ASME…..) and comply with customer specification
4. Design custody meter, non custody meter, truck loading and pipeline system
5. Design proving point suitable with compact prover
6. Design control system Flow Computer, PLC and DCS
7. Reliability

P-Procurement

1. Main Eqipment in Matering Skid and Truck Loading comply with customer AVL

Flow transmitter
Pressure Indicator, Temp Indicator, Pressure Transmitter, Temp Transmitter and Pressure Differentail Transmitter
Flow computer with Control Cabinet
Control Valve
Manual Valve
Strainer
Safety Relief Valve

2. Pipe, Flange, Fitting Bolt/Nut, Gasket
3. Steel Structure

C-Construction

1. Site Survey and Field Preparation Foudation for Metering Skid or Truck Loadin Skid
2. Fabrication Metering Skid and Truck Loading
3. NDE Inspetion comply with customer rate requirement
4. Pressure Test for Piping Work
5. Factory Acceptance Test
6. Transportation to Site and Plan Lifting Work for Installation
7. Safety

G-Government

1. Contact and Coordinate with W&M, Excise, customs and DMF
2. Permision Approval Letter Flow Meter Custody Transfer
3. Permision Approval Letter for 1st Proving Meter
4. Permision Approval Letter by W&M, Excise, Customs and DMF
